Arabian Drilling Tools offers the TA Center Latch 90° Collar Type Elevator, designed for handling casing, tubing, and drill pipes with collar connections. Featuring a center latch mechanism with a 90° opening design, this elevator ensures smooth and secure engagement during drilling operations.
Manufactured from high-quality alloy steel, the TA Center Latch Elevator undergoes strict heat treatment, load testing, and magnetic particle inspection to ensure superior strength, durability, and safety. The 90° collar type design makes it ideal for heavy-duty applications, providing operators with reliable performance and reducing handling time on the rig floor.
Available in a range of sizes and capacities up to 500 tons, the TA Center Latch 90° Collar Type Elevator complies with API 8C specifications, making it a trusted choice for safe and efficient tubular handling.
At Arabian Drilling Tools, we deliver elevators that combine engineering excellence with international safety standards to meet the demands of modern drilling operations.
TA Center Latch 90° Collar Type Elevator
Part Number & Sizes
Part No. | Tons | Size Range | Size of Links | Weight | |
|---|---|---|---|---|---|
| 56101 | 35 | 1.050″ – 2.7/8″ | 7/8″ – 1.3/4″ | 40 | |
| 56102 | 65 | 1.660″ – 2.7/8″ |
| 65 | |
| 56103 | 65 | 3.1/2″ – 4.1/2″ | 1.1/4″ – 2.3/4″ | 83 | |
56104 | 100 | 2.3/8″ – 2.7/8″ | 1.3/4″ – 2.3/4″ | 125 | |
| 56105 | 100 | 3.1/2″ – 4.1/2″ | 1.3/4″ – 2.3/4″ | 158 | |
| 56106 | 100 | 5.1/2″ – 8.5/8″ | 1.3/4″ – 2.3/4″ | 352 | |
| 56107 | 150 |
| 1.3/4″ – 3.1/2″ | 462 | |
| 56108 | 150 | 8.1/2″ – 11.3/4″ | 1.3/4″ – 3.1/2″ | 545 | |
